Fiberglass Reinforced Plastic FRP Pipe
Eastboom® is a Chinese pipe manufacturer fiberglass reinforced plastic FRP pipe, corrosion-resistant, and high-strength solutions for industrial transportation. Our fiberglass pipes offer durability, low maintenance, and a long service life, making them an ideal choice for industrial transportation.
Send Inquiry
Product Description
With customizable sizes, compliance with international standards, and extensive experience in energy, mining, and desalination projects, we are your trusted partner for durable infrastructure. Contact us today for a quote or technical consultation. We welcome collaborations worldwide.
Feature And Application
fiberglass reinforced plastic FRP pipe Features:
Mechanical Strength
Made with glass fiber reinforcement and thermosetting resin, our fiberglass reinforced plastic pipes offer high tensile and compressive strength, enabling them to withstand heavy loads and provide long-term service.
Excellent Corrosion Resistance
Suitable for conveying acids, alkalis, seawater, and industrial chemicals, they resist rusting, scaling, or chemical reactions, even in extreme environments.
Lightweight and Low Maintenance
Enhanced transportation, handling, and installation for greater ease and cost-effectiveness.
Wide Operating Temperature Range
Suitable for conveying low and high temperature fluids, they maintain structural integrity in a wide range of climates and industrial conditions.
Applications:
Power station cooling water systems
Industrial chemical fluid piping
Wastewater and drainage systems
Mining and petrochemical projects
Desalination plantsGet our technical catalog or consult with our engineering team for custom diameters, pressure ratings, and installation support.
Eastboom® — Your long-term partner in advanced composite piping systems.
|
Outside Diameter |
Inner Diameter |
||||
|
DN |
OD |
Deviation |
DN |
ID |
|
|
min |
max |
||||
|
mm |
mm |
mm |
mm |
mm |
mm |
|
200 |
208 |
+1.0，-1.0 |
100 |
97 |
103 |
|
250 |
259 |
+1.0，-1.0 |
125 |
122 |
128 |
|
300 |
310 |
+1.0，-1.0 |
150 |
147 |
153 |
|
350 |
361 |
+1.0，-1.2 |
200 |
196 |
204 |
|
400 |
412 |
+1.0，-1.4 |
250 |
246 |
255 |
|
450 |
463 |
+1.0，-1.6 |
300 |
296 |
306 |
|
500 |
514 |
+1.0，-1.8 |
350 |
349 |
357 |
|
600 |
616 |
+1.0，-2.0 |
400 |
396 |
408 |
|
700 |
718 |
+1.0，-2.2 |
450 |
446 |
459 |
|
800 |
820 |
+1.0，-2.4 |
500 |
496 |
510 |
|
900 |
924 |
+1.0，-2.6 |
600 |
595 |
612 |
|
1000 |
1026 |
+2.0，-2.6 |
700 |
695 |
714 |
|
1200 |
1229 |
+2.0，-2.6 |
800 |
795 |
816 |
|
1400 |
1434 |
+2.0，-2.8 |
900 |
895 |
918 |
|
1600 |
1638 |
+2.0，-2.8 |
1000 |
995 |
1020 |
|
1800 |
1842 |
+2.0，-3.0 |
1200 |
1195 |
1220 |
|
2000 |
2046 |
+2.0，-3.0 |
1400 |
1395 |
1420 |
|
2200 |
2250 |
+2.0，-3.2 |
1600 |
1595 |
1620 |
|
2400 |
2453 |
+2.0，-3.4 |
1800 |
1795 |
1820 |
|
2600 |
2658 |
+2.0，-3.6 |
2000 |
1995 |
2020 |
|
2800 |
2861 |
+2.0，-3.8 |
2200 |
2195 |
2220 |
|
3000 |
3066 |
+2.0，-4.0 |
2400 |
2395 |
2420 |
|
3200 |
3270 |
+2.0，-4.2 |
2600 |
2595 |
2620 |
|
3400 |
3474 |
+2.0，-4.4 |
2800 |
2795 |
2820 |
|
3600 |
3678 |
+2.0，-4.6 |
3000 |
2995 |
3020 |
|
3800 |
3882 |
+2.0，-4.8 |
3200 |
3195 |
3220 |
|
4000 |
4086 |
+2.0，-5.0 |
3400 |
3395 |
3420 |
|
|
|
|
3600 |
3595 |
3620 |
|
|
|
|
3800 |
3795 |
3820 |
|
|
|
|
4000 |
3995 |
4020 |
