The company focuses on engineering pipeline materials for agriculture and infrastructure. Agriculture Water Drip Irrigation System Polyethylene Drip Irrigation HDPE Pipe are supplied to projects that value stable quality, reasonable cost, and straightforward maintenance. Experience from domestic work has been extended to overseas markets, where feedback highlights practical performance in daily use.

Send Inquiry

Product Description

HDPE Drip Irrigation Pipe (Agricultural Water System)

Company Introduction

Material Features and Advantages

These drip irrigation pipes use polyethylene as the base material. The inner surface is smooth, which helps the water move with less resistance and reduces the chance of scale or sediment building up along long irrigation lines. Because the pipes are light and flexible, transport and installation are simpler than with rigid alternatives.

The material tolerates a wide range of soil and weather conditions and shows good resistance to common chemicals. Fusion welding is used for the joints, giving tight seals that limit leakage during long service. In practice, users often find that the overall system requires less maintenance and keeps operating costs under control.

Application Scenarios

- Greenhouse and open-field irrigation

- Municipal and industrial water supply lines

- Dredge and drainage systems

- Landscape watering and garden projects

Product Features (Basic Info)

• Model NO.: EB‑PE027

• Material: PE (HDPE/PE100)

• Kind: Thermoplastics Pipes

• Water Absorption: < 0.01%

• Contraction Percentage: < 0.4%

• Lifespan: Over 50 years

• Working Pressure: PN 4–20 bar

• Color: Black with blue stripe or as required

• Certificate: ISO (with optional CE/SGS)

• Length: 6 meters or as requested

• Connection: Fusion welding, socket fusion

• Working Temperature: −40 ºC to 40 ºC

• Shape: Round

• Usage: Irrigation; municipal; industrial

• Characteristic: Flexibility, corrosion resistance

• Main Application: Water supply, irrigation, dredge system

• Standard: GB/T 13663‑2000; ISO 4427‑1:2007

• Max Nominal Pressure: 0.6 MPa – 2.5 MPa

• Transport Package: 20′ or 40′ container

• Specification: DN 20–1600 mm

• HS Code: 3917210000

• Production Capacity: 400,000 t/year

Technical Parameters (Specification Sheet)

DN (mm)	SDR41 / PN4 0.4MPa	SDR33 / PN5 0.5MPa	SDR26 / PN6 0.6MPa	SDR21 / PN8 0.8MPa	SDR17 / PN10 1.0MPa	SDR13.6 / PN12.5 1.25MPa	SDR11 / PN16 1.6MPa	SDR9 / PN20 2.0MPa	SDR7.4 / PN25 2.5MPa
20	-	-	-	-	-	-	2.0	2.3	3.0
25	-	-	-	-	-	2.0	2.3	3.0	3.5
32	-	-	-	-	2.0	2.4	3.0	3.6	4.4
40	-	-	-	2.0	2.4	3.0	3.7	4.5	5.5
50	-	-	2.0	2.4	3.0	3.7	4.6	5.6	6.9
63	-	-	2.5	3.0	3.8	4.7	5.8	7.1	8.6
75	-	-	2.9	3.6	4.5	5.6	6.8	8.4	10.3
90	-	-	3.5	4.3	5.4	6.7	8.2	10.1	12.3
110	-	-	4.2	5.3	6.6	8.1	10.0	12.3	15.1
125	-	-	4.8	6.0	7.4	9.2	11.4	14.0	17.1
140	-	-	5.4	6.7	8.3	10.3	12.7	15.7	19.2
160	-	-	6.2	7.7	9.5	11.8	14.6	17.9	21.9
180	-	-	6.9	8.6	10.7	13.3	16.4	20.1	24.6
200	-	-	7.7	9.6	11.9	14.7	18.2	22.4	27.4
225	-	-	8.6	10.8	13.4	16.6	20.5	25.2	30.8
250	-	-	9.6	11.9	14.8	18.4	22.7	27.9	34.2
280	-	-	10.7	13.4	16.6	20.6	25.4	31.3	38.3
315	7.7	9.7	12.1	15.0	18.7	23.2	28.6	35.2	43.1
355	8.7	10.9	13.6	16.9	21.1	26.1	32.2	39.7	48.5
400	9.8	12.3	15.3	19.1	23.7	29.4	36.3	44.7	54.7
450	11.0	13.8	17.2	21.5	26.7	33.1	40.9	50.3	61.5
500	12.3	15.3	19.1	23.9	29.7	36.8	45.4	55.8	-
560	13.7	17.2	21.4	26.7	33.2	41.2	50.8	62.5	-
630	15.4	19.3	24.1	30.0	37.4	46.3	57.2	70.3	-
710	17.4	21.8	27.2	33.9	42.1	52.2	64.5	79.3	-
800	19.6	24.5	30.6	38.1	47.4	58.8	72.6	89.3	-
900	22.0	27.6	34.4	42.9	53.3	66.2	81.7	-	-
1000	24.5	30.6	38.2	47.7	59.3	72.5	90.2	-	-
1200	29.4	36.7	45.9	57.2	67.9	88.2	-	-	-
1400	34.3	42.9	53.5	66.7	82.4	102.9	-	-	-
1600	39.2	49.0	61.2	76.2	94.1	117.6	-	-	-
