China Threaded PVC Pipe Manufacturer, Supplier, Factory
Threaded PVC Pipe is engineered to deliver exceptional performance across a wide range of demanding applications. A primary use for this versatile product is in high-pressure fluid transport, making it a reliable choice as a Plastic Water Pipe. Its corrosion-resistant properties also make it an ideal choice for use as a PVC Electrical Conduit, providing superior protection for wiring systems in both indoor and outdoor environments. To ensure a complete and secure installation, our threaded pipe is fully compatible with a comprehensive range of PVC Conduit Fittings. Furthermore, its robust design and leak-proof threaded connections are perfectly suited for modern PVC Plumbing systems in residential, commercial, and industrial settings, offering a durable and cost-effective solution.
Threaded PVC Pipe is manufactured from high-grade, unplasticized Polyvinyl Chloride (uPVC) compound. This material composition ensures the pipe possesses excellent tensile strength and impact resistance, allowing it to withstand significant internal pressure and external loads. The threads are precision-cut to industry standards, guaranteeing a tight, secure seal when connected with corresponding fittings, which minimizes the risk of leaks and system failure. The inherent properties of PVC make Threaded PVC Pipe highly resistant to a broad spectrum of chemicals, abrasion, and environmental stress cracking. It is also non-conductive, adding an extra layer of safety for electrical applications. The smooth interior wall minimizes friction loss, promoting efficient flow of liquids and gases. This product is lightweight, which simplifies handling and installation, reducing labor time and costs.
Key Specifications of Threaded PVC Pipe
- Material: Schedule 80 uPVC (Unplasticized Polyvinyl Chloride)
- Standards: Complies with ASTM D1784, ASTM D1785, NSF/ANSI 61, and UL 651
- Temperature Range: Suitable for use in environments from 0°F to 140°F (-18°C to 60°C)
- Pressure Rating: Varies by size; e.g., 1/2" pipe rated for 600 PSI at 73°F
- Thread Type: NPT (National Pipe Taper) threads standard
- Color: Standard gray for electrical conduit; other colors like white available upon request
| Nominal Size (Inches) | Outside Diameter (Inches) | Wall Thickness (Inches) | Approximate Weight per 10ft Section (lbs) |
|---|---|---|---|
| 1/2 | 0.840 | 0.109 | 1.2 |
| 3/4 | 1.050 | 0.113 | 1.6 |
| 1 | 1.315 | 0.133 | 2.5 |
| 1 1/4 | 1.660 | 0.140 | 3.6 |
| 1 1/2 | 1.900 | 0.145 | 4.5 |
| 2 | 2.375 | 0.154 | 6.4 |
